Plan of Beatrice
Plan of Beatrice
Plan of Beatrice

Plan of Beatrice

Associated (North Sea oil platform, went into production in 1981)
Date21st Century
Object NamePlan
Mediumboard
ClassificationsNorth Sea Oil and Gas Industries
DimensionsOverall (Height x Width): 382 x 585 mm
AcquisitionPresented in 2022.
LocationView by Appointment - Aberdeen Treasure Hub
Object numberABDMS095778.8.8
About MeOne of a number of plans of the Beatrice platform depicting its various layouts and features. These were located on the platform itself to provide information for workers based on their current location.
